• Pole-Position：Momentary Type,SPST With LED
• Contact Rating：30VDC,0.1A
• Contact Resistance：By Method of Voltage Drop
• Insulation Resistance：
• Dielectric Strength：500 VAC for 1 Minute
• Operating Force：250±100gf
• Operating Life：50,000 cycles
• Operating Temperature Range：-40℃ ~ 85℃
• Total Travel：1.2±0.3mm
|
 |
   |
| Part Number | Pole-Position | Contact Rating | Contact Resistance | Dielectric Strength | Operating Force | Operating Life | Operating Temperature Range | Total Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R2902A-XX-XX | Momentary Type,SPST With LED | 30VDC,0.1A | By Method of Voltage Drop | 500 VAC for 1 Minute | 250±100gf | 50,000 cycles | -40℃ ~ 85℃ | 1.2±0.3mm | 暫無(wú) |
| R2902A-K(Non-LED) | Momentary Type,SPST With LED | 30VDC,0.1A | By Method of Voltage Drop | 500 VAC for 1 Minute | 250±100gf | 50,000 cycles | -40℃ ~ 85℃ | 1.2±0.3mm | 暫無(wú) |
