• Contact Rating：50mA,12VDC
• Contact Resistance：100mΩ max
• Travel：0.25mm
• Insulation Resistance：100mΩ min.500VDC
• Dielectric Strength：250VAC/1 minute
• Operating Force：160±50gf
• Operating Temp.：-40℃ ~+85℃
• Operating Life：1,000,000 cycles
• Storage Temp.：-40℃ ~+85℃
|
 |
   |
| Part Number | Contact Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Operating Temp. | Travel | Operating Life | Storage Temp. | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|---|
| R2992-M□□□Q-T/R | 50mA,12VDC | 100mΩ max | 100mΩ min.500VDC | 250VAC/1 minute | 160±50gf | -40℃ ~+85℃ | 0.25mm | 1,000,000 cycles | -40℃ ~+85℃ | 暫無 |
