• Contact Rating：50mA,24 VDC
• Contact Resistance：50mΩ max.(initial)
• Insulation Resistance：10MΩ min.100VDC
• Dielectric Strength：250VAC/1 min
• Operation Temperature：-40℃ to + 160℃
• Electric Life：1，000，000 cycles
|
 |
   |
| Part Number | Contact Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operation Temperature | Electric Life | PDF下載 |
|---|---|---|---|---|---|---|---|
| R2091-T4-1H-□□-V | 50mA,24 VDC | 50mΩ max.(initial) | 10MΩ min.100VDC | 250VAC/1 min | -40℃ to + 160℃ | 1，000，000 cycles | 暫無 |
| R2091-T-1M2-□□-V | 50mA,24 VDC | 50mΩ max.(initial) | 10MΩ min.100VDC | 250VAC/1 min | -40℃ to + 160℃ | 1，000，000 cycles | 暫無 |
| R2091-T1-0M1-□N-V | 50mA,24 VDC | 50mΩ max.(initial) | 10MΩ min.100VDC | 250VAC/1 min | -40℃ to + 160℃ | 1，000，000 cycles | 暫無 |
| R2091-T1-0M3-□N-V | 50mA,24 VDC | 50mΩ max.(initial) | 10MΩ min.100VDC | 250VAC/1 min | -40℃ to + 160℃ | 1，000，000 cycles | 暫無 |
| R2091-T4-0H-□□-S□-V | 50mA,24 VDC | 50mΩ max.(initial) | 10MΩ min.100VDC | 250VAC/1 min | -40℃ to + 160℃ | 1，000，000 cycles | 暫無 |
| R2091-T4-0H-□□-G□-V | 50mA,24 VDC | 50mΩ max.(initial) | 10MΩ min.100VDC | 250VAC/1 min | -40℃ to + 160℃ | 1，000，000 cycles | 暫無 |
| R2091-T2-0H-□N-V | 50mA,24 VDC | 50mΩ max.(initial) | 10MΩ min.100VDC | 250VAC/1 min | -40℃ to + 160℃ | 1，000，000 cycles | 暫無 |
| R2091-T2-0H-□N-T□-V | 50mA,24 VDC | 50mΩ max.(initial) | 10MΩ min.100VDC | 250VAC/1 min | -40℃ to + 160℃ | 1，000，000 cycles | 暫無 |
| R2091-T1-0H3-□N-V | 50mA,24 VDC | 50mΩ max.(initial) | 10MΩ min.100VDC | 250VAC/1 min | -40℃ to + 160℃ | 1，000，000 cycles | 暫無 |
