• Rating：12VDC 50mA
• Contact Resistance：100mΩ Max
• Insulation Resistance：100MΩ min(250VDC)
• Dielectric Strength：250VAC 50/60Hz FOR 1 min
• Operating Force：160±50g/250±80g
• Electric Life：100,000/50,000 cycles
• Operating Temperature Range：-20℃ ~ + 70℃
• Travel：0.25±0.1 mm
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Electric Life | Operating Temperature Range | Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R591B-211L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R591B-211 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R591B-211ML(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R591B-211M | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R591B-2RW | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R591B-21RW | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R591B-2RWL(25)(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R591B-21RWL(25)(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R591B-2RWL(45)(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R591B-21RWL(45)(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R591B-21RL(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R591B-21R | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
