• Rating：50mA 12VDC
• Contact Resistance：100mΩ Max.(Initial)
• Insulation Resistance：1GΩ Min (at 250 VDC)
• Dielectric Strength：AC 250V(50/60 Hz for 1 minute)
• Operating Force：400±100gf
• Electrically Life：10,000 Cycles Min
• Ambient Temperature：-40℃ ~+125℃
• Total Travel：0.5(0.8)mm
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Electrically Life | Ambient Temperature | Total Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R2990L-B-C | 50mA 12VDC | 100mΩ Max.(Initial) | 1GΩ Min (at 250 VDC) | AC 250V(50/60 Hz for 1 minute) | 400±100gf | 10,000 Cycles Min | -40℃ ~+125℃ | 0.5(0.8)mm | 暫無 |
